Description
As Yeti's most versatile bike the SB140 hits that sweet spot of efficient riding kinematics with aggressive geometry and suspension platform. Truly mixing the disciplines of mountain biking to result in the ultimate trail bike. The Lunch Ride build kits add some extra jazz to the SB140 by upping the travel, making the bike more eager for rougher trails and features.
The all new 29" wheeled SB140 boasts a brand new frame design packed with all the yeti race-proven design knowledge and the latest mountain biking technologies. At the bikes core is the 160mm front/140mm rear platform with the newly updated Switch Infinity system. This sweet spot of travel makes for a perfectly balanced bike that truly makes easy work of all types of trail.
The SB140 is available in 2 build kits, the C-Series 2 and Turq Series 3. T-Series Yeti frames are manufactured using their finest carbon layup. The result is the best possible balance of stiffness, compliance and aesthetics (it really is difficult to show in pictures the sublime level of detail put into every Yeti frame). The C-Series frames are identical in geometry but make use of a different carbon lay-up, this makes the frame more affordable, at the cost of a little extra weight.
The C-Series bikes now come fitted with Fox factory suspension!
LR (LUNCH RIDE) -
Yeti Lunch Ride bikes up the front travel from the standard versions adding a little extra spice to the ride. The SB140 seen here in LR guise has 160mm front travel compared to the 150mm found on standard models
SWITCH INFINITY -
Switch Infinity utilizes a patented translating pivot that switches direction as the bike moves through its travel. This provides a tailored anti-squat curve while delivering a fine-tuned leverage ratio
Switch Infinity decouples chain forces from suspension forces incredibly effectively. In the beginning and mid-section of travel – when Switch Infinity moves up – a relatively flat and high anti-squat curve creates an efficient pedalling platform through the entire pedalling zone. As a result, suspension performs consistently and predictably. When Switch Infinity reverses direction, anti-squat drastically drops for freedom of suspension movement
SIZING -
- S: 5'1 - 5'7
- M: 5'5 - 5'11
- L: 5'10 - 6'3
- XL: 6'1 - 6'7
- XXL: 6'5 - 6'11
Specifications
-
Discipline Trail/Enduro
-
Material Turq Carbon
-
Front Travel 160mm
-
Rear Travel 140mm
-
Wheel Size 29"
-
Warranty Lifetime (frame)
FRAME - TURQ Series carbon fibre frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing, 148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.
FORK - FOX FACTORY 36 GRIP 2/160MM
SHOCK - FOX FACTORY FLOAT X
TYRE (F) - MAXXIS MINION DHF 2.5 EXO
TYRE (R) - MAXXIS MINION DHR II 2.4 EXO
ROTOR (F) - SRAM CENTERLINE 200
ROTOR (R) - SRAM CENTERLINE 180
HEADSET - CANE CREEK 40 INTEGRATED
WHEELSET - DT SWISS XM1700 30MM
BB - SRAM DUB BSA 73
GRIPS - ODI ELITE PRO
BAR - YETI CARBON 35X780MM
STEM - BURGTEC ENDURO MK3 35X50MM
CRANK - SRAM X0 EAGLE TRANSMISSION 30T 170MM
SADDLE - SILVERADO CUSTOM
BRAKES - SRAM CODE RSC
DERAILLEUR - SRAM X0 EAGLE AXS TRANSMISSION
CASSETTE - SRAM X0 EAGLE TRANSMISSION 10-52
CHAIN - SRAM X0 EAGLE TRANSMISSION FLATTOP
SHIFTER - SRAM AXS POD CONTROLLER
SEATPOST - FOX TRANSFER 31.6MM / 175MM
-
Discipline Trail/Enduro
-
Material C Carbon
-
Front Travel 160mm
-
Rear Travel 140mm
-
Wheel Size 29"
-
Warranty Lifetime (frame)
FRAME - C-Series carbon fibre frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing, 148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.
FORK - FOX FACTORY 36 GRIP 2/160MM
SHOCK - FOX FACTORY FLOAT X
TYRE (F) - MAXXIS MINION DHF 2.5 EXO
TYRE (R) - MAXXIS MINION DHR II 2.4 EXO
ROTOR (F) - SRAM CENTERLINE 200
ROTOR (R) - SRAM CENTERLINE 180
HEADSET - CANE CREEK 40 INTEGRATED
WHEELSET - DT SWISS M1900 30MM
BB - SRAM DUB BSA 73
GRIPS - ODI ELITE PRO
BAR - BURGTEC RIDEWIDE 35X780MM
STEM - BURGTEC ENDURO MK3 35X50MM
CRANK - SRAM GX EAGLE 30T 170MM
SADDLE - SILVERADO CUSTOM
BRAKES - SRAM CODE R
DERAILLEUR - SRAM GX EAGLE
CASSETTE - SRAM GX EAGLE 10-52
CHAIN - SRAM GX EAGLE
SHIFTER - SRAM GX EAGLE
SEATPOST - ONEUP 31.6MM
