Description
The eOne-Forty shares exactly the same frame and design features as the headline grabbing eOne-Sixty though has different ride characteristics. The eOne-Forty is the option to go for if fast trail riding with the occasional visit to a bikepark is your mountain biking style of choice.
The shock stroke on the eOne-Forty is shorter, reducing rear travel to 133mm and creating a steeper seat angle. The shorter 140mm fork extends the reach, delivering a slightly steeper head angle. In combination these small changes make the eOne-Forty more agile and playful; a highly competent climber that's perfect for all day riding.
The mixed wheel size set up is carried over, to give the e-full suspension bikes precise steering, fantastic ‘rolling over obstacles’ behaviour yet maximum traction, a 29er front wheel with a 2.5" tyre is combined with a 650B rear wheel, equipped with a slightly wider 2.6" tyre. The perfect combination of precision, playfulness and traction.
All eOne-Forty models use the powerful Shimano EP600 85NM motor and bigger 630Wh battery (with the exception of frame size - S which uses 504Wh).
Shimano's e-Tube app allows you to tailor power delivery to suit your riding style; you can set two profiles; one for shredding and one for cruising.
- Tough all-aluminium chassis with integrated 630 Wh battery
- New, powerful Shimano EP6 drive unit with 85 Nm torque
- Mixed wheel size setup with 140/130 mm travel split
- Quality Marzocchi and SR Suntour suspension
- Wide range Shimano drivetrain
- Powerful four-piston brakes
Merida Warranty -
Merida are proud to offer a fantastic warranty policy. In the unlikely event that you have an issue with the bike frame, motor or components, Merida personally take care and supply replacement parts to get you out riding asap.
Specifications
-
Discipline Trail/All-Mountain
-
Material Aluminium
-
Front Travel 150mm
-
Rear Travel 143mm
-
Wheel Size 29"
-
Warranty Lifetime (frame)
FRAME - Lite III - Hydroformed 6061 Double butted aluminium with integrated battery. Internal cable routing via Smart entry ports. Tapered head tube, 148 x 12mm axle standard. Max. tyre size 27.5" x 2.8".
MOTOR - Shimano Steps EP6; 85Nm
BATTERY - Shimano EN806; 630Wh internal battery
BATTERY CAPACITY - 630Wh
EBIKE DISPLAY - Shimano SC-EN500
CHARGER - Shimano EC-E6002; 2A Charging current
POWER BUTTON - Merida Power Cap button
MODE SWITCH - Shimano SC-EN500
SHOCK - Suntour RS-Edge-TR-LO-R8-M6; lockout
FORK - Marzocchi Z2 eMTB+; Air; 140mm travel; Tapered; 51mm fork offset. Max. tyre size: 29" x 2.6"
GEARS - 11
SHIFTERS - Shimano Deore M5100 and Shimano SL-MT500-IL dropper post lever
REAR DERAILLEUR - Shimano Deore RDM5100 11
BOTTOM BRACKET - Part of Shimano Steps motor
CHAIN - KMC e11S EPT
CHAINSET - Shimano CRE70-B; 34 tooth chainring with Shimano FC-EM600; 165mm length crank
CASSETTE - Shimano M5100; 11-51 teeth; 11 speed
BRAKE LEVER - Shimano M4204
FRONT BRAKE - Shimano M4204 4 piston hydraulic disc brake caliper with Shimano RT30 203 mm rotor
REAR BRAKE - Shimano M4204 4 piston hydraulic disc brake caliper with Shimano RTEM300 203 mm rotor
GRIP - Merida Expert EC
HANDLEBAR - Merida Expert eTR; 780mm wide; 20mm rise
STEM - Merida Expert eTR II; aluminium; 35mm diameter; 0 degree rise - stem length: 50mm all sizes; GoPro & Supernova mount
HEAD SET - Merida-8152
PEDAL - VP Components - VPE-537
SADDLE - Merida Comp SL with V-mount
SEAT POST - Merida Comp TR; 30.9mm diameter; in-line; Drop: 100mm (S), 125mm (M/L), 150mm (XL/XXL)
WHEEL SIZE - 29" / 27.5"
RIMS - Merida Comp TR; 29mm inner rim width; Aluminium
SPOKES - Black stainless
FRONT HUB - Shimano MT400-B; 110x15mm; 32 spokes; Center lock
REAR HUB - Shimano MT400-B; 148x12mm; 36 spokes; Center lock; including removable lever with 4/6mm Allen key
FRONT TYRE - Maxxis Rekon; 29" x 2.4"; wire bead; dual
REAR TYRE - Maxxis Rekon; 27.5" x 2.6"; wire bead; EXO
FRONT LIGHT - Lezyne eBike Power STVZO E115 front light
REAR LIGHT - USB REAR Light CG-214RG
OTHER - Complete with: mini fenders and front / rear lights. Shimano Satellite charging port; EW-CP100
