Description
Marin's entry level electric mountain bike is a jack-of-all-trades and and superb option for those looking to jump into power assisted trail riding.
The Rift Zone range handles fast-trail duty for Marin. With modern aggressive geometry paired with mid travel numbers and rapid 29" wheels the Rift Zone is insanely fun to ride and more than capable of handling big terrain features. Whether at a local trail centre or bike park, the Rift Zone will perform.
One of the very best value eMTB’s around, the base model Marin Rift Zone E packs a crazy-powerful punch without busting the bank. RockShox and X-Fusion handle the suspension, Shimano Deore brings a tough, reliable 10-speed drivetrain and Shimano’s STEPS EP6 drive unit powers you up, along and down. A 504WH battery is supplied as standard, with the option to upgrade to a beefy 630WH for even more range.
SIZING -
- S: 5'3 - 5'6
- M: 5'6 - 5'10
- L: 5'10 - 6'1
- XL: 6'1 - 6'4
Specifications
-
Discipline Trail/All-Mountain
-
Material Aluminium
-
Front Travel 140mm
-
Rear Travel 140mm
-
Wheel Size 29"
-
Warranty 5 Years (frame)
FRAME - All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
FORK - RockShock 35 Silver R 29", Motion Control Damper, 140mm Travel, Maxle Stealth Axle, 42mm Offset
SHOCK - X-Fusion 02 PRO R, Compression and Rebound Adjustment, Custom Tune, 210x50 25xM8 Lower Mount & Upper Mount
RIMS - Marin Aluminium Double Wall, 29" Diameter, 29mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible
HUB REAR - Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body
HUB FRONT - Shimano FH-TC500, 110x15mm, Centerlock, 32H
SPOKES - 14g Black Stainless Steel
TYRES - Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing
DERAILLEUR REAR - Shimano Deore, Direct Attachment, 10-Speed SGS
SHIFT LEVER - Shimano Deore, 10-Speed, I-Spec EV
CRANKSET - Shimano EM600, 160mm Length, 38t Chainring
MOTOR - Shimano Steps EP6 Drive Unit, 250W, 85Nm
CHAIN - KMC X-10E, Silver
CASSETTE - Shimano Deore 10-speed 11-46T
BRAKES FRONT - TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick
BRAKES REAR - TRP Slate EVO 4-Piston Hydraulic
BRAKE LEVERS - Shimano MT4100 Hydraulic, I-Spec EV Compatible
HANDLEBAR - Marin Mini-Riser, 6061 Double Butted Aluminium, 780mm Width, 28mm Rise, 5º Up, 9º Back
STEM - Marin 3D Forged Alloy, 35mm
GRIPS - Marin Grizzly Lock On
HEADSET - FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
SEATPOST - TranzX, YSP18JL, 1x Remote, Size S 150mm Travel, All Other Sizes 170mm Travel, 30.9mm
SADDLE - Marin eMTB Saddle
PEDALS - Marin MTB Plastic
BATTERY - Shimano BT-EN805L, Internal 504Wh
DISPLAY - Shimano SC-E600
SWITCH - Shimano SW-EN600L Left Hand Switch for Assist Mode Change
EXTRAS - Shimano Battery Charger EC-E6002, Shimano CS-EN800 Chainguide
