Description

The HD6 is the evolution of one of the most successful enduro bikes in history. Designed with input from our Enduro World Cup team and building upon our award-winning Ripmo and HD lines, the HD6 features increased travel, a completely redesigned suspension layout, and mixed wheels.

COIL COMPATIBLE - Ibis' upper link suspension layout is progressive enough to be sensitive off the top, yet supportive enough for the biggest hits. It is also compatible with all coil shocks, for those longer race stages that can tax air shock performance.

DW-LINK - The suspension layout may be new, but it’s still DW-Link. The inherent efficiency means you don’t need an overdamped shock to climb well. Less shock damping allows the wheels to stay planted on the ground, providing more traction and that hover-bike feel that our frames are known for. The HD6 climbs with a finesse that defies its enduro race pedigree.

SIZING -

  • S: 5'2 - 5'6
  • M: 5'5 - 5'9
  • XM: 5'8 - 6'
  • L: 5'11 - 6'3
  • XL: 6'2 - 6'7



Frame Material - Carbon front and rear triangle
Frame Weight - A size large HD6 frame with an X2 weighs 7.7 lbs / 3.5kg
Wheel Size - 29/27.5” mixed wheelsize, up to 2.5" tyre clearance
Front Travel - 180mm
Rear Travel - 165mm
Shock Specs - 230 x 65mm
Shock Eyelet Hardware - 25mm x 8mm front / 15mm x 8mm rear
Boost Axles - 148mm rear / 110mm front
Seatpost Diameter - 34.9mm
Rear Brake - 180mm Post mount / 220mm max rotor
Chainstay Length - 435mm
Bottom Bracket - Threaded (73mm BSA)
Chainline - 55mm chainline
Chainring - 30T - 34T
Derailleur Hanger - SRAM UDH
ISCG 05 Compatible - ISCG 05 Tab Mount available separately
Headset - ZS44 upper / ZS56 lower
Colours - Traffic Cone Orange, Enchanted Forest Green or Lavender Haze
Sizes - SM (1) /MD (2) /XM (3) /LG (4) /XL (5)
Frame Warranty - Lifetime

Ibis HD6 Frame

SKU: HDC3LVS00000025 / Barcode: 840345314482

The HD6 is the evolution of one of the most successful enduro bikes in history. Designed with input from our Enduro World Cup team and building upon our award-winning Ripmo...

Regular price £3,699.00
Colour

Size

In stock

90 Day Returns -

Description

The HD6 is the evolution of one of the most successful enduro bikes in history. Designed with input from our Enduro World Cup team and building upon our award-winning Ripmo and HD lines, the HD6 features increased travel, a completely redesigned suspension layout, and mixed wheels.

COIL COMPATIBLE - Ibis' upper link suspension layout is progressive enough to be sensitive off the top, yet supportive enough for the biggest hits. It is also compatible with all coil shocks, for those longer race stages that can tax air shock performance.

DW-LINK - The suspension layout may be new, but it’s still DW-Link. The inherent efficiency means you don’t need an overdamped shock to climb well. Less shock damping allows the wheels to stay planted on the ground, providing more traction and that hover-bike feel that our frames are known for. The HD6 climbs with a finesse that defies its enduro race pedigree.

SIZING -

  • S: 5'2 - 5'6
  • M: 5'5 - 5'9
  • XM: 5'8 - 6'
  • L: 5'11 - 6'3
  • XL: 6'2 - 6'7



Frame Material - Carbon front and rear triangle
Frame Weight - A size large HD6 frame with an X2 weighs 7.7 lbs / 3.5kg
Wheel Size - 29/27.5” mixed wheelsize, up to 2.5" tyre clearance
Front Travel - 180mm
Rear Travel - 165mm
Shock Specs - 230 x 65mm
Shock Eyelet Hardware - 25mm x 8mm front / 15mm x 8mm rear
Boost Axles - 148mm rear / 110mm front
Seatpost Diameter - 34.9mm
Rear Brake - 180mm Post mount / 220mm max rotor
Chainstay Length - 435mm
Bottom Bracket - Threaded (73mm BSA)
Chainline - 55mm chainline
Chainring - 30T - 34T
Derailleur Hanger - SRAM UDH
ISCG 05 Compatible - ISCG 05 Tab Mount available separately
Headset - ZS44 upper / ZS56 lower
Colours - Traffic Cone Orange, Enchanted Forest Green or Lavender Haze
Sizes - SM (1) /MD (2) /XM (3) /LG (4) /XL (5)
Frame Warranty - Lifetime
