Since 2005, the FOX 36 has led the single crown fork market with best-in-class performance and unrivalled stiffness-to-weight ratio.

The Fox 36 Float Performance Elite Grip X Fork 2026 has been revamped for even better performance on All-Mountain terrain. With an enhanced chassis and increased bushing overlap, the 36 now boasts 20% more torsional stiffness compared to its predecessor, bringing it closer to the steering capabilities of the 38.

The 36 Float Performance Elite Grip X Fork 2026 features an updated FLOAT air spring and internal bypass channels for a significantly smoother ride throughout its travel, making it especially beneficial for higher loads and faster speeds.

As rough terrain becomes more of a challenge for all-mountain riders, the need for uncompromised bike handling increases. With the 36 Float Performance Elite Grip X Fork 2026, riders can experience the same Enduro ride feel as a 38 without any added weight.

ARCH TO RIVAL

Generatively designed and optimised by FOX engineers, the new 36 arch wraps around the lowers to increase torsional stiffness of the fork by a full 20%. This now gives the 36 a veritable 87% of the torsional stiffness found on the 38 (up from 75%), while remaining 275g lighter than the 38.

COMPLIANT AIR SPRING. FOR SMOOTHNESS UNDER LOAD.

A large enough bending force—such as hitting a large rock or root at high speed—can cause the air spring to bind to the inside of the stanchion when the fork is compressing through its travel.

The redesigned and compliant FLOAT air spring decouples the stanchion from the air shaft, allowing the piston to move with the fork while under these bending loads, rather than resisting them.

The result? Smoother suspension action overall, especially when the fork is experiencing high loads from speed or weight of a rider.

MORE BUSHING OVERLAP

As the fork is loaded sideways (such as running over an obstacle on the trail), that bending force is translated from the lower leg to the stanchions through Teflon-lined sleeves called bushings. “Bushing overlap” refers to the distance between upper and lower bushings in each leg.

In suspension forks, this greater overlap reduces friction between the stanchions and lower legs throughout the stroke. By adding an additional 30mm of bushing overlap over the previous 36, chassis friction is reduced significantly for a smoother-feeling fork overall, as well as adding fore-aft stiffness for a more stable-feeling at higher speed.

GRIP X — UNCOMPROMISED ALL-MOUNTAIN PERFORMANCE

Trail riders no longer need to choose between a descent-focused damper or a lightweight endurance damper. GRIP X exudes the exemplary descent performance of GRIP X2, refined for less weight, easier set up and an easy access firm mode for pedalling efficiency.

INBOARD BYPASS CHANNELS

Bypass channels help curb pressure ramping for increased small bump sensitivity, as well as recirculating oil to lubricating bushings and seals. By relocating the bypass channels from the aft side of the fork to the inboard side, they are now out of the fore-aft load path. This further reduces friction and wear, as well as increasing overall sensitivity of the fork.

ADDED UTILITY

1. Low profile bleeders. Grooved design allows pressure to escape around your finger as you press the bleeder.
2. Air spring top cap. Now uses the common Shimano cassette tool for easy volume adjustments.
3. Mudguard. Mounts to seal flanges and arch instead of bleeder ports. Refined aesthetic, durability and seal protection. Long and short styles.

Specification

• Wheel Size: 29, 27.5
• Travel: 140mm, 150mm, 160mm
• Rake: 37mm, 44mm offset (27.5) / 44mm offset (29)
• Axle: KABOLT 15 QR ON Performance Series
• Rotor Size: 200-230mm
• Air Spring: FLOAT EVOL Complaint
• Steerer: 1.5 Taper
• Starting Weight: 1920g (29 160MM GRIP X)
